Milton 12 Volt Fuel Pump (15 GPM)
CCC Parts Item #: ISNMILZE925
Vendor Part #: MILZE925
This item has been superseded but the link to that part is not currently working. Please try again or contact Expert Care customer service.
Product Description
12 Volt Fuel Pump (15 GPM), Aluminum die cast construction, UL approved explosion proof motor with sintered powered gears, NBE seals, 34 two piece suction tube designed to fit 55 gallon drums, Positive displacement, Duty cycle: 30 minutes ON, 30 minutes OFF, Removable wire mesh strainer for easy cleaning without disassembling the pump,Wetted components are: aluminum, steel, cast iron, nylon, NBR, zinc, FKM, polypropylene, and PVC, Motor: 12 Volt DC 1/7-HP, Inlet: 1 NPT, Outlet: 3/4 NPT
Product Detail & Specification
Specifications
Retail Vendor Code:
WB
Description:
12 Volt Fuel Pump (15 GPM), Aluminum die cast construction, UL approved explosion proof motor with sintered powered gears, NBE seals, 34 two piece suction tube designed to fit 55 gallon drums, Positive displacement, Duty cycle: 30 minutes ON, 30 minutes OFF, Removable wire mesh strainer for easy cleaning without disassembling the pump,Wetted components are: aluminum, steel, cast iron, nylon, NBR, zinc, FKM, polypropylene, and PVC, Motor: 12 Volt DC 1/7-HP, Inlet: 1 NPT, Outlet: 3/4 NPT
Part Name:
12 Volt Fuel Pump (15 GPM)
Brand:
Milton
Short Description:
12 Volt Fuel Pump (15 GPM)
Part Number:
WBMILZE925
Vendor Part Number:
MILZE925
Height:
7
Width:
15
Length:
24
Weight:
32
Parts Classification:
Parts Classification>>Air and Fuel Delivery>>Fuel Pumps and Related Components>>Electric Fuel Pump (6256)
Unit of Measure:
EACH
LTL Required:
tpltlrequired-68934a3e9455fa72420237eb05902327
Bar Code:
15954409250
NMFC Code:
121875-NULL-70|MISCELLANEOUS TRUCK PARTS, includes Transmission/Clutch Parts, Gears, Pumps, etc
Cross References
Warranty
- For warranty details, see the Warranty Claims section.
